PA Nylon Clear eSun filament

Description

eSUN ePA (Nylon) Filament – ​​High-strength nylon plastic filament.

eSUN ePA is a nylon/polyamide filament for 3D printers designed for printing high-durability engineering components. This filament is exceptionally tough, flexible, and wear-resistant, making it ideal for creating mechanical parts, gears, or prototypes that need to withstand impact.

Key Features:

  • High toughness and impact resistance: Highly impact-resistant, not easily broken, and inherently flexible.

  • Wear Resistance: Suitable for parts subject to friction or movement, such as gears or nuts.

  • Chemical and heat resistant: Highly resistant to oil, grease, and various chemicals, and can withstand higher temperatures than typical PLA filament.

  • High precision: Manufactured to rigorous standards, resulting in consistently round lines and reducing nozzle clogging problems (No Clogging).

  • Transparent: The plastic material is translucent, resulting in a beautiful and smooth surface finish.

  • Environmentally friendly: No toxic substances and low odor during printing.

Specifications:

  • Material: Nylon (Polyamide)

  • Diameter: 1.75 mm

  • Weight: 1 kilogram (per roll)

  • Color: Natural / Transparent

Printing Parameters:

  • Print head temperature (Nozzle Temp): 260 - 280°C (recommended at 265°C)

  • Bed temperature: 70 - 90°C

  • Fan Speed: 0% (Fan off)

  • Print Speed: 40 - 100 mm/s

  • Base material (Build Surface): We recommend using PVA glue sticks or PEI sheets to aid in adhesion.

⚠️ Important Tips:

  1. Moisture: Nylon is a highly hygroscopic material. The filament must always be completely dry before printing (using a filament drying box such as the eSUN eBOX is recommended) to prevent air bubbles and uneven surfaces.

  2. Adhesion: Nylon typically does not adhere to a bare glass base. Adhesive is needed to prevent the piece from peeling or warping.

Caution: ePA or Nylon yarns are highly absorbent. Avoid moisture, and the yarn should be kept dry during use to prevent moisture damage.

The filament must be cured at 70 degrees Celsius for more than 12 hours before printing.

Product form

1,199.00 ฿

  • Shipped today? Order within: Jul 04, 2026 11:00:00 +0700
  • Fast Delivery
Chat on LINE and FB Messenger

Description

eSUN ePA (Nylon) Filament – ​​High-strength nylon plastic filament.

eSUN ePA is a nylon/polyamide filament for 3D printers designed for printing high-durability engineering components. This filament is exceptionally tough, flexible, and wear-resistant, making it ideal for creating mechanical parts, gears, or prototypes that need to withstand impact.

Key Features:

  • High toughness and impact resistance: Highly impact-resistant, not easily broken, and inherently flexible.

  • Wear Resistance: Suitable for parts subject to friction or movement, such as gears or nuts.

  • Chemical and heat resistant: Highly resistant to oil, grease, and various chemicals, and can withstand higher temperatures than typical PLA filament.

  • High precision: Manufactured to rigorous standards, resulting in consistently round lines and reducing nozzle clogging problems (No Clogging).

  • Transparent: The plastic material is translucent, resulting in a beautiful and smooth surface finish.

  • Environmentally friendly: No toxic substances and low odor during printing.

Specifications:

  • Material: Nylon (Polyamide)

  • Diameter: 1.75 mm

  • Weight: 1 kilogram (per roll)

  • Color: Natural / Transparent

Printing Parameters:

  • Print head temperature (Nozzle Temp): 260 - 280°C (recommended at 265°C)

  • Bed temperature: 70 - 90°C

  • Fan Speed: 0% (Fan off)

  • Print Speed: 40 - 100 mm/s

  • Base material (Build Surface): We recommend using PVA glue sticks or PEI sheets to aid in adhesion.

⚠️ Important Tips:

  1. Moisture: Nylon is a highly hygroscopic material. The filament must always be completely dry before printing (using a filament drying box such as the eSUN eBOX is recommended) to prevent air bubbles and uneven surfaces.

  2. Adhesion: Nylon typically does not adhere to a bare glass base. Adhesive is needed to prevent the piece from peeling or warping.

Caution: ePA or Nylon yarns are highly absorbent. Avoid moisture, and the yarn should be kept dry during use to prevent moisture damage.

The filament must be cured at 70 degrees Celsius for more than 12 hours before printing.

Frequently Asked Questions

  • PA Nylon คืออะไร?

    PA (Polyamide) เป็นวัสดุวิศวกรรมที่แข็งแรงสูง ทนการสึกหรอดีเยี่ยม ยืดหยุ่นได้บ้าง และทนสารเคมีหลายชนิด

  • ต้องตั้งอุณหภูมิเท่าไหร่?

    อุณหภูมิหัวฉีด 240–270°C ฐานพิมพ์ 80–100°C แนะนำให้ใช้ตู้ปิดเพื่อลดการโก่งงอ และทา Adhesive บนฐานพิมพ์ หัวฉีดทองเหลืองปกติใช้ได้สำหรับ Nylon ล้วน

  • ทำไม Nylon ต้องอบแห้งก่อนพิมพ์ทุกครั้ง?

    Nylon ดูดซับความชื้นจากอากาศได้เร็วมาก (Hygroscopic) ความชื้นที่สะสมจะระเหยเมื่อถูกความร้อน ทำให้เกิดเสียงดัง ฟองอากาศ และผิวชิ้นงานไม่เรียบ ควรอบที่ 70–80°C นาน 4–8 ชั่วโมง

  • PA Nylon Clear eSun filament เหมาะกับงานอะไรบ้าง?

    เหมาะสำหรับเฟือง บูช แบริ่ง สายพาน ชิ้นส่วนยานยนต์ และชิ้นส่วนกลไกที่ต้องรับแรงเสียดทานสูง

  • ควรเก็บรักษา Nylon Filament อย่างไร?

    ต้องเก็บในถุงสุญญากาศหรือกล่องปิดที่มีสารดูดความชื้นตลอดเวลา แม้แต่ 30 นาทีในอากาศชื้นก็ทำให้เส้นดูดชื้นจนคุณภาพพิมพ์ลดลงได้

  • Nylon มีความแข็งแรงแค่ไหนเมื่อเทียบกับ PLA?

    Nylon มีความแข็งแรงดึงสูงกว่า PLA และมี Fatigue Resistance สูงกว่ามาก เหมาะกับชิ้นส่วนที่รับแรงซ้ำๆ

  • ความเร็วพิมพ์ที่เหมาะสมเท่าไหร่?

    แนะนำ 40–60 mm/s และใช้ Fan เป่าเบาๆ หรือปิด Fan เพื่อลดการโก่งงอ

  • ต้องทา Adhesive บนฐานพิมพ์ไหม?

    แนะนำอย่างยิ่ง ใช้กาวสติ๊ก Dimafix หรือ 3DLac บนฐานพิมพ์ที่ร้อน เพื่อให้ชั้นแรกยึดเกาะดีและลดโอกาสชิ้นงานหลุดระหว่างพิมพ์
